QH--15bbl Brewhouse for brewery
QH--15bbl Brewhouse for brewery
15 bbl two-vessel or three-vessel or four vessel brewhouse
Mash vessel – with mixer, frequency drive
Lauter tun – false bottom, plough, sparging
Boiling kettle/whirlpool tun- steam jackets or calandria, tangential entry
Pumps with ABB motor
Stainless steel 304 working platform
Plate heat exchanger – 304 or 316 plates
Siemens PLC control system, UL rated control system
15 bbl and 30 bbl fermentation tanks/bright beer tanks
HLT and CLT
Glycol cooling system
CIP system
Grain milling machine
Keg washer/filler
Great quality, reasonable price, excellent service!
Complete engineering support and onsite installation!
Please contact us for more details!
15BBL Brew House/Micro Brewery
| No. | System | Equipments components | Specification | Quantity |
| 1 | Milling system | Malt mill | 500kgs/H | 1 |
| Flexible conveyor | 500kgs/H | 1 | ||
| Grist hopper | 1500L | 1 | ||
| 2 | Mashing system | Mash tun | 15BBL | 1 |
| Lauter tun | 15BBL | 1 | ||
| Boil kettle | 15BBL | |||
| Whirlpool tun | 15BBL | 1 | ||
| Hot liquid tank | 30BBL | 1 | ||
| Brewhouse centirfugal pump | 5T/H | 4 | ||
| Hops filter | 50L | 1 | ||
| Wort balance tank | 15L | 1 | ||
| Plate heat exchanger | 20m2 | 1 | ||
| Wort food hose | Assorted | Assorted | ||
| Pipeline and valves | ||||
| Operation Platform | ||||
| 3 | Fermenting system | Fermenter | 15BBL | 3 |
| 30BBL | 2 | |||
| 45BBL | 1 | |||
| Brite tank | 15BBL | 1 | ||
| Yeast feeder | 50L | 1 | ||
| 4 | Glycol cooling system | Glycol liquid tank | 30BBL | 1 |
| Cold water tank | 30BBL | 1 | ||
| Glycol liquid pump | 4T/H | 1 | ||
| Cold water centrifugal pump | 5T/H | 1 | ||
| Glycol chiller | 10HP | 2 | ||
| Glycol liquid pipeline | Assorted | Assorted | ||
| 5 | Control system | PLC control box | Touch screen | 1 |
| 6 | CIP system | Alkali tank | 200L | 1 |
| Sterilization tank | 200L | 1 | ||
| CIP control cabinet | Digital control | 1 | ||
| CIP pump+pipeline valve | Assorted | 1 | ||
| 7 | Accessories | Spare parts (Extra) | Assorted | 1 |
| 8 | Steam boiler | Natural gas steam boiler | 200kgs/H | 1 |
| Necessary element | Pipes&valves | SUS304 | Assorted |
1. Brewhouse system
-Two-Four vessles or combined system.
-Capacity 100L-5000L, 1bbl-40bbl.
- Steam heated, electrical heated or natural gas
-Mash tun with mixer, steam jacket, VFD motor, insulated 80mm. Stainelsss steel 304.
-Lauter tun with rake system, milled false bottom, sparging spray ring, VFD motor, insulated 80mm.
-Boiling kettle with steam jacket, inner heated option, insulated 80mm. Stainelsss steel 304.
-Whirlpool with Tangential whirlpool inlet. insulated 80mm. Stainelsss steel 304.
-Insulated HLT and CLT with the pipelines and pumps
-External wort balance tank, hops filter, heat exchanger. Wort oxygenation system, working platform.
-All the necessary pipelines and pumps.
2. Fermentation System- Beer Fermenter and brite tanks
-Usage: fermentation, maturation and storage
1-Domed head and conical bottom
2-Material: SUS 304, inner thickness 3mm, outer thickness1.5mm, Insulation: PU=80mm
3-Top manway
4-Cone bottom, 60 degree
5-Pressure gauge
6-Safety/vacuum valve
7-Working pressure: 0.15Mpa
8-Testing pressure: 0.3Mpa
9-Cooling jackets on both cylinder and cone
10-Inside 360 rotating CIP ball
11. Rotating Racking arm
12-Thermowell, 10mm
13-Temperature sensor, Model: PT100
14-Wort piping and butterfly valves, ø32mm
15-Drainage piping and butterfly valve, ø38mm
16-3 or 4 legs with adjustable bolts
-carbonation stone (optional)
- dry hops port (optional)
3.Cooling System
Description: Air-cooled type chiller + Ice water tank or Glycol tank
Capacity: 3HP, 5HP, 7HP, 10HP, 15HP, 20HP, 30HP+ 500L-20000L tank
4.Control System
-PID or PLC system
-SIEMENS program S7-200, Siemens touch screen.
-Penumatic valves for optional
5. CIP system
1) Alkali tank with heating function
2) Sterilization tank
3) CIP pump
4) Control cabinet
